Barber Colman model 16-36 Horizontal gear hobber style type A, 16″ Diam, x 36″ Cut Length, A-frame style, machine is complete with Hob arbor and misc change gears , inspect in our NC plant under power
- Homepage
- >
- Barber Colman model 16-36 Horizontal gear hobber style type A, 16″ Diam, x 36″ Cut Length, A-frame style, machine is complete with Hob arbor and misc change gears , inspect in our NC plant under power
Category: GEAR HOBBERS, HORIZONTAL – See Also H4500
Reference Number: 4123
Description:
Barber-Colman Horizontal Gear hobber Machine
s/n 517
A-frame style machine
This Horizontal style hobbing machine can be inspected under power in good operating condition. the machine corresponds to the following specifications and equipped as follows
Machine specifications
*Max DP in Steel
6 DP-10 DP
*Max Work OD
16″
*Max Hob Slide Travel
36″
*Diameter Hole Thru Work Spindle
3-/1/8″
*Max Hob Diameter
5″
*Max Distance Face of Work Spindle to Tailstock 40″
*Max Vertical Adjustment of Work Spindle
8″
*Max Hob Slide Swivel Angle Setting-Degree
45 degrees
*9 Hob Speeds
59-246 RPM
*Hob Feeds
.0075-.1125″
MACHINE IS EQUIPPED WITH:
1 Hob Arbor
Rapid traverse
Manual hob shift
tailstock with screw type center
a-frame style machine
Dual start worm
3-Jaw precision chuck
Misc. Change Gears
Machine can be inspected under power with proper notice in our Statesville NC facility!
For any questions contact Rich Piselli
E-mail:
rich@pisellient.com
Phone: 704.609.0766
